Chevrolet Impala Ignition Repair in Fort Worth (2026): Switch & Cylinder

TL;DR — Impala ignition trouble in one screen

Three distinct failures produce complaints that sound identical when a Chevrolet Impala owner describes them over the phone. Sorting them before anyone buys a part is the entire job.

• Mechanical: the ignition lock cylinder. The key will not rotate, or rotates only with a jiggle that gets worse over weeks. Cause is wafer wear. This is the most common of the three.
• Electrical: the ignition switch. The key rotates normally but a position does nothing — no dash, no accessory, or no crank in start. The switch sits behind the cylinder and knows nothing about keys.
• Theft-deterrent: Passlock or the later immobilizer. The key rotates, the dash lights up, the engine fires and dies after about a second, usually with a security light on the cluster.

Fort Worth working range for ignition repair: $150-$400, covering everything from a cylinder replacement re-keyed to your existing key up to a seized-cylinder extraction plus an electrical switch.

If the engine cranks and dies rather than refusing to turn, start on the no key detected / immobilizer path instead of this one — it is a different repair with a different price.

The three-way split, in order of how you test it

The reason Impala ignition complaints get misdiagnosed is that the driver experiences one event — the car will not start — while three independent subsystems can produce it. Each is a different part, a different failure mode, and a different bill.

Test one: does the key physically rotate?

Insert the key and try to turn it. If it binds, catches, or will not move, stop. The problem is mechanical and lives in the lock cylinder. Nothing electrical is implicated yet because the sequence never got that far.

Test two: with the key rotating, does each position do its job?

Accessory should power the radio and accessories. Run should light the full cluster and enable the fuel pump prime. Start should crank the engine. If one or more of those positions is dead while the key rotates freely, the electrical switch is the suspect. A common Impala presentation is a car that has accessory and run but never cranks — that is a start-contact failure inside the switch, not a bad starter.

Test three: does it crank and then die?

If the engine turns over, catches, and dies about one second later, both mechanical and electrical parts did their jobs. The theft-deterrent system refused to authorize fuel. Look for a security or key icon illuminated on the cluster. This is a Passlock or immobilizer diagnosis and is covered in depth under GM theft-deterrent system.

Test four: does the steering wheel release?

If the key rotates but the wheel stays locked hard against its stop, the column lock actuator is binding. Related but distinct, and covered under steering column lock repair.

Those four tests take under ten minutes with the shroud off. Any operator who quotes a part before running them is guessing with your money.

Why the 2006-2020 Impala generates so many of these calls

Two things stack up on this platform: production volume and fleet history.

The Impala sold in very large numbers across this window, and a substantial share of the 2006-2016 cars went into rental, government, and commercial fleets before entering the retail used market. Fleet cars accumulate key cycles at rates that dwarf a private car — multiple drivers, multiple daily starts, keys handled roughly and carried on crowded rings.

The arithmetic is straightforward. A private daily driver puts the key in and out somewhere between four and eight times a day, or roughly 15,000 to 30,000 cycles a year. A fleet car can run several times that. Cumulative totals in the 80,000 to 150,000 cycle range are entirely ordinary by the time one of these cars reaches a second or third owner, and that is the neighborhood where wafer stacks start losing the shear line.

There is also a generational overlap that confuses quoting, exactly as it does on the Malibu. Chevrolet continued building the previous-generation W-body Impala as the Impala Limited for fleet buyers during 2014-2016, alongside the redesigned tenth-generation car. Two very different vehicles, same model year on the title. Check the badge and check the column before assuming anything from the registration.

The mechanical failure: wafer wear in the lock cylinder

Inside the ignition lock is a brass or zinc barrel holding a stack of spring-loaded wafers. The correct key pushes each wafer to a precise height so that all of them sit flush with the barrel wall — the shear line. Only then can the barrel rotate and drive the switch behind it.

Two components wear at once. The wafer edges develop flats and rounded corners from tens of thousands of blade passes. The key blade itself loses material where it contacts those wafers. Either alone is survivable. Together, the tolerance stack eventually exceeds what the shear line can absorb, and the cylinder binds.

That is why the failure is gradual, not sudden. Owners describe the same arc almost verbatim: an occasional wiggle, then a weekly wiggle, then every cold morning, then a car that will not start in a parking lot on the west side of town.

The key contributes more than people think. A decade of carrying the ignition key on a ring loaded with house keys, a fob, and a carabiner side-loads the blade every time the car is driven. The blade bends microscopically and wears unevenly. A brand-new key cut fresh from the vehicle's key code will often turn a marginal cylinder that the old key no longer will. That makes a fresh key both a cheap diagnostic and occasionally the entire fix — and it produces a useful spare regardless of outcome. The cutting side of that is covered under car key cutting.

The electrical failure: the ignition switch

The ignition switch is a separate component behind the lock cylinder. It has discrete detented positions and internal contacts that route battery power to different circuits. It has no idea a key exists; it only knows something rotated it.

Switch failures on high-mileage GM cars typically present in one of four ways:

1. No power in any position. Key rotates, dash stays dark.
2. Accessory works, run does not. Radio comes on, cluster never fully lights.
3. Run works, start does not. Everything looks normal but the starter never engages. This is the one most often misdiagnosed as a bad starter or a dead battery.
4. Intermittent dropout with column movement. Dash flickers or the engine stumbles when the wheel is bumped or the column is jostled. That is a contact or connector fault, and it is the version worth fixing quickly because it can drop electrical load while the car is moving.

That fourth pattern is the safety-relevant one. Ignition and column hardware sits directly at the intersection of theft prevention and driver safety, which is a large part of why the National Highway Traffic Safety Administration publishes guidance on anti-theft and ignition equipment at all. An intermittent switch is not a convenience problem.

The theft-deterrent failure: Passlock and what came after

General Motors used several theft-deterrent approaches across this era, and the names get applied loosely in conversation. Two matter here.

Passlock places a resistive sensor in the ignition lock housing. When the correct key rotates the cylinder, the sensor reports a specific resistance value to the control module, and the module authorizes fuel. There is no chip in the key. It was inexpensive and effective, but the sensor and its wiring are the weak point: vibration, heat cycling, and age degrade them, and a degraded sensor reports the wrong value.

The classic Passlock signature is unmistakable once you know it. Security light on the cluster, engine starts and immediately dies, often triggered by rough road vibration or extreme temperature. Critically, cutting a new key does nothing for this. The key was never carrying the credential. Any operator who sells a Passlock-fault Impala a new key has sold that customer a part they did not need.

Transponder and proximity immobilizers appear on the later Impala. Here an encrypted chip in the key head, or a rolling-code radio link in a proximity fob, authenticates to the body control module. This is a genuine key-carried credential, so a key or fob problem genuinely can be the cause — and a new key genuinely can be the fix.

Distinguishing the two is a scan-tool question, not a guessing question. The Insurance Institute for Highway Safety's vehicle theft research documents why manufacturers accepted the occasional stranded owner as the price of these systems: they measurably reduce theft loss, and every one of them is designed to fail closed.

Symptom-to-cause reference table

The timed relearn nobody warns you about

General Motors platforms are known for timed security relearn procedures. On Passlock-family systems, the relearn has classically been structured as three consecutive ten-minute cycles with the ignition held in a specific state — roughly thirty minutes of the car sitting there doing apparently nothing.

This is by design. A thief cannot afford to sit in a stolen car for half an hour in a parking lot, so the delay is itself the security feature. It is not a fault, and it is not a technician stalling.

Two practical implications. First, current diagnostic tooling with proper security access can often shorten or avoid the wait entirely, which is one of the concrete reasons credentialed tooling is worth what it costs. Second, if a relearn is required on your car, an honest operator tells you before dispatch so that a ninety-minute appointment does not feel like a two-hour ambush.

What actually happens on site

An Impala ignition repair is a hand-tool job at the steering column. There is no lift, no alignment rack, and nothing that requires the car to be driveable — which is exactly the point, since a car with a dead ignition usually cannot be driven anywhere.

The sequence a credentialed technician follows:

1. Verify ownership. Title or current registration in your name plus a matching government-issued photo ID. Company vehicles need the registration plus a letter of authorization on letterhead. This applies to ignition work as fully as to key work, because anyone who can rebuild an ignition lock can start the car. The framework behind that expectation is the NASTF Vehicle Security Professional program.
2. Run the four tests. Rotation, power at each position, crank-and-die behavior, and steering lock release — plus a scan for stored fault codes. This is where the three-way split gets resolved rather than assumed.
3. Remove the column shrouds and access the lock housing and switch.
4. Extract the cylinder if it is the identified fault. Normally the retaining detent is depressed with the key at accessory. On a fully seized cylinder that is impossible, and controlled extraction is required — slower, and the reason a seized job lands at the top of the range.
5. Re-key the replacement cylinder to your existing key code, wafer by wafer, and bench-test rotation before installation.
6. Replace the electrical switch only if testing showed a specific electrical failure. Ask which one. Expect a specific answer.
7. Perform any required theft-deterrent relearn and verify the security light extinguishes.
8. Verify everything. All switch positions, engine start, steering lock cycle, shrouds reinstalled.
9. Written invoice with parts, labor, company license number, and warranty terms.

Typical on-site time is 45 to 90 minutes for a straightforward cylinder replacement, longer with a seized cylinder, an electrical switch, or a timed relearn in the sequence.

Choosing an operator without getting burned

Ignition work is a category where the customer has almost no leverage — you are standing next to an immobilized car in a parking lot, and the operator knows it. The Federal Trade Commission's guidance on hiring a locksmith lays out the defenses, and they apply directly:

• Insist on a flat-rate range before dispatch. A twenty-nine-dollar service-call teaser for ignition work is a hook, not a price. The FTC's truth-in-advertising standards are the benchmark that advertised number is supposed to meet.
• Confirm licensing. Texas locksmith companies are licensed through the Texas DPS Private Security Program — not the TDLR. Ask for the company license number and expect it printed on the invoice.
• Expect ownership verification. An operator willing to rebuild your ignition without checking a title would do the same for someone who is not you.
• Get the diagnosis in words before the parts. "Your cylinder is bound, the switch tests good in all four positions, so we are replacing the cylinder only" is a diagnosis. "It needs an ignition" is a sales line.

The Associated Locksmiths of America maintains the credentialing standards behind those expectations.

The same discipline carries across the GM lineup. Whether the job in front of you is an Impala column or a Chevrolet Silverado key replacement, the rule does not change: diagnose the subsystem, then sell the part, and never the reverse. Broader make coverage is on the Chevrolet brand page.

The real cost of waiting

A sticky ignition is one of the few car problems that is strictly cheaper to fix early, and the gap is not marginal.

Repaired while it still turns with a jiggle, it is a scheduled 45-to-90-minute driveway appointment inside the $150-$400 band. Repaired after the blade snaps off inside a seized cylinder, it is an extraction plus a cylinder at the top of that band, on a car that is now genuinely immobile and would need a tow to reach any shop.

Then there is downtime, which people consistently underestimate. The AAA analysis of annual driving costs is a reasonable frame for what an unavailable vehicle actually costs once rideshare fares, missed work, and rental days are counted. On a car that quits on a Tuesday morning, those figures pass the repair bill quickly.

As of July 2026 the advice is unchanged: the day it needs a wiggle is the day to book it. Same-day mobile coverage across Fort Worth and the surrounding cities is available through 24-hour car locksmith and the Fort Worth service area page.

Field-operator perspective

On the older Impalas the call I hate is the one where someone already bought and installed an ignition cylinder off the internet for a Passlock fault. The key was never the credential on that car — the sensor in the housing was. So they spent the money, did the labor, and the security light is still on and it still dies after a second. Ten minutes with a scan tool at the start would have told them exactly which of the three problems they actually had.

— a NASTF-registered Fort Worth automotive locksmith (anonymized)

Frequently Asked Questions

Why will my Chevrolet Impala key not turn in the ignition?

On a 2006-2020 Impala the leading cause is wafer wear inside the mechanical ignition lock cylinder. Every insertion drags the key blade across a stack of spring-loaded brass wafers, and after roughly 80,000 to 150,000 cycles neither the wafers nor the worn blade can reliably align at the shear line. The symptom is progressive: first it needs an occasional jiggle, then a jiggle every morning, then it stops. If the key rotates fine and the problem is electrical instead, you are looking at the switch, not the cylinder.

How do I tell an ignition switch problem from an ignition cylinder problem?

Test rotation and power separately. If the key will not physically rotate, the mechanical lock cylinder is the suspect. If the key rotates through every position but the dash stays dark, or accessory works while run does not, or run works while the starter never engages, the electrical switch is the suspect. If the key rotates, the dash lights up, and the engine cranks then dies after about a second, neither part is at fault and you are looking at the theft-deterrent system instead.

What is a Passlock fault and how does it act on an Impala?

Passlock was General Motors resistive theft-deterrent approach, using a sensor in the ignition lock housing that reports a specific resistance value when the correct key rotates the cylinder. When the sensor or its wiring degrades, the module reads the wrong value and disables fuel. The classic signature is a security light on the cluster plus an engine that starts and immediately dies, often appearing after rough road vibration or in temperature extremes. Cutting a new key does not fix a Passlock fault, which is why a real diagnosis comes first.

How much does Impala ignition repair cost in Fort Worth?

As of July 2026 ignition repair runs 150 to 400 dollars. The lower end covers a straightforward lock cylinder replacement re-keyed to your existing key on a car whose key is still in good condition. The upper end covers a seized cylinder that has to be extracted, or a cylinder plus an electrical switch replacement. Fort Worth Car Keys quotes a flat range before dispatch rather than a starting-at number, and the invoice lists parts, labor, and the company license number.

Can you fix the ignition without giving me a new key?

In most cases yes. A replacement lock cylinder can be re-keyed to your existing key by rebuilding its wafer stack to match your current cut. That keeps one key operating the doors and the ignition and avoids touching the transponder entirely, because the chip lives in the key head and the key head never changes. The exception is a key blade worn so badly that copying it would just recreate the failure, in which case a fresh key is cut from the vehicle key code.

Why does a GM ignition job sometimes include a waiting period?

Certain General Motors theft-deterrent relearn procedures are timed by design. The vehicle sits in a specific ignition state for a set interval, and on Passlock-family systems that relearn has classically run in the range of thirty minutes, structured as three consecutive ten-minute cycles. It is an anti-theft measure, not a malfunction. Current tooling with proper security access can often shorten or avoid the wait, but it should be built into your time expectations rather than come as a surprise on site.

Can this be repaired in my driveway or does the car need a shop?

Driveway is the normal setting. Impala ignition lock cylinder and switch work is done through the steering column shroud with hand tools, with no lift or alignment equipment involved. Fort Worth Car Keys works mobile only, Monday through Sunday, 8 AM to 8 PM, so the vehicle stays where it is. That matters here more than on most repairs, because an Impala with a dead ignition frequently cannot be driven to a shop in the first place and would otherwise need a tow.

References

1. NHTSA — Anti-Theft Systems — Federal guidance on ignition, immobilizer, and anti-theft equipment.
2. NASTF — Vehicle Security Professional Program — Credentialed access to OEM key-code and security data.
3. Associated Locksmiths of America (ALOA) — Trade association and certification body for the locksmith trade.
4. FTC Consumer Advice — Hiring a Locksmith — Verifying a locksmith and avoiding bait pricing.
5. FTC — Truth in Advertising — Standards governing advertised service pricing.
6. IIHS — Vehicle Theft — Research on theft losses and vehicle security hardware.
7. AAA — Your Driving Costs — Vehicle ownership, downtime, and unscheduled repair cost data.
